Wharfedale Pro M16 - MIC - Compressor

12
MIC - Compressor
Gate
Compressor
0dB
-10dB
-20dB
-30dB
-40dB
-50dB
-60dB
D
T
0dB
-10dB
-20dB
-30dB
-40dB
-50dB
-60dB
R
T
Range
0dB -80-40-20
ON
Reduction
0dB -80-40-20
OFF
8. 3 m s
Release
20.0 dB
858. 0ms
Hold
-20.0 d B u
Threshold
8. 3 m s
Attack
20.0 dB
20.0 d B
Range
8. 3 m s
Attack
20.0 dB00.dB
Gain
8. 3 m s
Release
-20.0 d B u
Threshold
20.0 dB
Ratio
20.0 d B
0.0 dB
C OPY
LINK
MIC3&4
Edit
E Q
COMP
MIC 1-C omp
Library
Side Chain
1
3
2
4
1. Gate.
The Y-axis represents the threshold and the X-axis
represents the time factor. The rising line determines
the attack time.The horizontal curve is the hold time,
and the descent line determines the release time.
1.1. On/Off.
Tap this button to enable or disable the Gate.
The default is Off.
1.2. Threshold.
Threshold Range is from -56dB to 0dB. The default is -56dB.
1.3. Attack:
Attack time is from 0ms to 100ms. The default is 0ms.
1.4. Release:
The Release time is from 2ms to 2000ms. The default is 2ms.
1.5. Hold:
The Hold time is from 2ms to 2000ms. The default is 2ms.
1.6. Range:
The Range is from -80dB to 0dB. The default is -80dB
2. Compressor.
2.1. On/Off
Tap this button to enable or disable Compressor.
The default is Off.
2.2. Threshold:
The Threshold Range is from -56dB to 0dB.
The default is -56dB.
2.3. Attack:
The Attack time is from 0ms to 100ms. The
default is 0ms.
2.4. Release:
The Release time is from 2ms to 2000ms.
The default is 2ms.
2.5. Gain:
Gain is from -12dB to +12dB. The default is -12dB.
2.6. Ratio:
The Ratio is from 1.0 to 20.0. The default is 1.0
3. Side Chain
Click the drop-down button to select the side chain
channel from the list.
The user can select Pre or Post EQ channel settings
for the Side Chain.
4. Compressor Library
Uses the same style of operation as found in the
EQ Library.
