5.4.4. Removing the front drive base
The disassembly procedure is indicated on the label.
① ③②
1.
Raise the base release handle.
The lock between the front drive base and rear drive
base is released.
Base release
handle
2.
Grab the handle in the central area of the front drive
base and disconnect Bar B on the top of the front drive
base from the hook of the rear drive base.
Support the rear drive base with a hand while
disconnecting so that the rear drive base does not
fall over.
Handle
Bar B
Rear drive base
Front drive base
