WHILL Model F User Manual
3
3. Assembly and adjustment
8.
Install the controller removed in step 3 to the arm rest
on the opposite side.
Insert the grooved part of the controller to the
projection on the arm rest, then slide the controller.
Install the screw and fixture removed in step 5, and
tighten the screw to fix the controller.
Try to move the installed controller up, down, left,
and right, and check it they are locked in place.
9.
Connect the cable disconnected in step 2 to the outer
side cover removed in step 4.
10.
Install the cover removed in step 4 to the arm rest with
controller.
