WHILL F - Changing the Space between Arm Rests

50
WHILL Model F User Manual
3
3.3.2. Changing the space between arm rests
The space between arm rests can be widened by altering the installation method.
Standard: Controller facing inwards
(inside width 430 mm)
Wide: Controller facing outwards
(inside width 480 mm)
1.
Remove the battery.
For the removal procedure, refer to “4.1.1. Removing
the battery” on page 59.
2.
Remove the seat cushion from the seat.
Seat cushion
