WHILL Model F User Manual
3
3.3.1. Adjusting the height of the arm rest
This following procedure introduces an example where the controller is installed on the right arm.
1.
Remove the battery.
For the removal procedure, refer to “4.1.1. Removing
the battery” on page 59.
2.
Loosen the arm rest adjustment screw.
To loosen a re-tightened screw, use a Phillips
screwdriver.
Arm rest adjustment screw
3.
Change and adjust the locking position of the arm rest
to the desired height.
Set the position so that the scale on the arm rest is
aligned with the upper end of the arm.
The height of the arm rest can be adjusted in 3
stages.
To Next Page
