WHILL Model F User Manual
3
3. Assembly and adjustment
4.
Tighten the arm rest adjustment screw loosened in
step 2, and x the arm resist in place.
Arm rest adjustment screw
5.
Adjust the height of the arm rest on the opposite side
in the same way.
6.
Install the battery.
For the installation procedure, refer to “3.2.8. Installing
the battery” on page 46.
• After adjustment is completed, try to slide the
arm rest up and down to confirm that it is locked
in place and does not slide.
• If rattling of the arm rest bothers you, further
tighten the arm rest adjustment screw with a
Phillips screwdriver.
To Next Page
