DIAGNOSTICS & TROUBLESHOOTING
Whirlpool Smart All-In-One Washer & Dryer
n
2-7
For Service Technician Use Only
Connued on following page . . .
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.


Fault codes are displayed by showing F#E#. The F# indicates
the suspect System/Category. The E# indicates the suspect
Component system.
The fault codes below may be indicated under various
condions and can be accessed through Service Diagnoscs.



 Load in drum during Clean Washer cycle Remove load and re-start Clean Washer cycle.
 Oversuds Excessive suds in washer. Washer is running a suds reducon
roune. If the washer is unable to correct the problem, this
may indicate:
• Not using HE detergent.
• Excessive detergent usage.
• Check pressure hose connecon from tub to main
control. Is hose pinched, kinked, plugged, or leaking air.
 High temp error, dry cycle, no air ow Detected dryer fan not funconing properly. Try recycling
power to washer/dryer.
• Check thermal cut-o. See TEST #12a: Dry Heang
Element, pg. 3-19.
• Check dry NTC. See TEST #12b: Dry Temperature Sensor
(NTC), pg. 3-20.
• Check dry fan motor. See TEST #13: Dry Fan Motor, pg.
3-21.
 High temp error, wash cycle Washer water too hot. May have water inlet hose
connected to hot water faucet.
• Make sure inlet hose is connected to a cold water faucet.
• Check wash heat element. See TEST #8: Wash Heang
Element, pg. 3-12.
• Check wash temperature sensor. See TEST #9: Wash
Temperature Sensor, pg. 3-13.
 O Balance Load Load could be unbalanced or too large. Avoid ghtly packing
the load. Avoid washing single items.
 MCU over- or under-voltage error MCU malfuncon, voltage out of range.
• See TEST #3: Motor Circuit, page 3-7.
 Main relay open or shorted Main relay issue. Try recycling power to washer/dryer.
• See TEST #1: ACU Power Check, pg. 3-4.
 Pressure switch signal missing or out of range See TEST #6: Pressure Switch, pg. -10.
 Wash NTC open or shorted See TEST #9: Wash Temperature Sensor, pg. 3-13.
See TEST #12b: Dry Thermistor Sensor, pg. 3-20.
