Protocol VLAN configuration,delete ERPS ring protocol VLAN (<2-4094>)
Data VLAN Configuration ERPS Ring Data VLAN (<1-4094>)
Ring port Configuration, delete ERPS ring port, RPL port or common ring port
Restore Behavior Configure ERPS ring recovery behavior, recoverable or
unrecoverable
hold-off Time Configure the ERPS loop hold-off time (<0-10000>), in ms, the default is 0
Guard Time Configure the ERPS ring guard time (<10-2000>), in ms, defaults to 500
Wtr Time Configure the ERPS ring wtr time (<1-12>), in min, default to 5
Wtb Time Configure the ERPS ring wtb time (<1-10>), in seconds, the default is 5
Protocol packet transmission time Configure the sending time of the ERPS ring
protocol packets (<1-10>), in seconds, the default is 5
Enable ERPS ring Turn the ERPS ring on or off
Force to switch ERPS ring port Forced, clear to switch ERPS ring port
Force manual ERPS ring port Force, remove manual ERPS ring port
Manual recovery Handle recovery of ERPS ring's unrecoverable behavior or manual
recovery before WTR / WTB expires
（2）ERPS information page
Figure 70 shows the ERPS information page, where users can view the ERPS
configuration information.
20、Log management
（1）Log information
Figure 71 shows the log information page, the user can view the log through this page.
Select the priority from the drop-down list, you can view the log of that level, click Refresh to
view the latest log.
