2. Operation
2.6.2 Service level
In der Serviceebene können Messwerte, Parameter, Akto-
rentest und Einstellungen angezeigt, geändert bzw. durch-
geführt werden.
Values
Parameters
Actuator test
Settings
Choose Back
1 only displayed when an MESplus control is present and this has been adjusted by a trained service technician in the basic settings.
Fig. 46
Operator level
Service level
Information level
MES Module
1
Choose Back
Information!
Changes on the Service level may be perfor-
med only by trained service personnel (direc-
tions for setting, see the LogWIN assembly in-
structions)
Fig. 47
Service level only for trained
service personnel
5sec
The menu item or sub-menu item is exited by pressing the
Back button (Fig. 48) or after a delay of 45 seconds.
Fig. 48
