86333220 CS20 101
Scrub Deck Lift
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86271660 2 NUT 4-40 HEX NYLOCK
2 86007160 4 SWITCH 10A ROLLER MINI
3 86327390 2 SCR, 4-40 X 2 PPHMS
4A 86323850 1 PLATE, SWITCH ACTUATOR DISK
4B 86346540 1 PLATE, SWITCH ACTUATOR CYLINDRICAL
5 86320880 1 ACT, 36VDC, 3.0" STK, 8.74 LNG
6 86328040 1 PIN, CLEVIS, 1/4 X 2.0 L
7 86008650 2 COTTER 1/4" RING
8 86336790 1 PIN, CLEVIS, 1/4 X 2.50. PLTD *(2)
9 86279610 1 WASHER, SEAL 1/4X5/8OD SS
10 86338480 1 GUIDE PLATE ASM *(2)
11 86010630 1 WASHER 1/4 ID X 5/8 OD SS
12 86264940 1 CABLE TIE, 11.38" UL/CSA *(2)
13 86342240 1 SPACER, .81 X 1.06 X .125 *(4)
*SEE SERIAL NUMBER PAGE
To Next Page
