Windsor chariot iScrub 20 CS20 User Manual

86333220 CS20 107
Squeegee
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86332060 4
RIV-NUT, HEX, 5/16-18X.562, CLEAR
CAD
2 86327860 1 SQUEEGEE BLADE RETAINER ASSY
3 86327790 6 PLATE, WEIGHT, SQUEEGEE
4 86326520 2 SCR, 5/16-18 X 2.25 HHCS SS
5 86326510 1 PIVOT SHAFT, LATCH
6 86326490 4 SCR, 5/16-18 X 3.0 CARRIAGE SS
7 86326480 4 SCR, 1/4-20 X 2.25 CARRIAGE SS
8 86326470 1 BRACE, SQUEEGEE COVER
9 86326460 1 CASTER, 1-5/8, 3/8-24 SHT STUD
10 86326450 1
RECEIVER, LATCH PLATE,
SQUEEGEE
11 86326440 2 LIFT BRKT, BUMPER, SQUEEGEE
12 86326420 1 SPRING, RUBBER
13 86326400 1 RECEIVER, LATCH, SQUEEGEE
14 86326070 1 BLADE, SQUEEGEE, REAR, DURO 40
15 86326060 1
BLADE, SQUEEGEE, FRONT, DURO
40
- 86342050 BLADE, SQUGE, FRONT, URTHN 38A OPTION
- 86342060 BLADE, SQUGE, REAR, URTHN 38A OPTION
16 86323910 1 VACUUM TUBE, SQUEEGEE
17 86320730 1 COVER, SQUEEGEE-RH
18 86320720 1 COVER, SQUEEGEE-LH
19 86292500 4 WASHER, .324ID X .567OD X .057, SS
20 86001350 2 BUSHING, SPANNER .435 X 1.10
21 86011020 2 WHEEL, 3" DIA. CUSHION RUBBER
22 86010880 2 WHEEL, 1.5 OD X .31 ID X .75 W GRY
23 86010650 2 WASHER, #10 X 9/16 FLAT
24 86010630 4 WASHER, 1/4 X 5/8 FLAT SS
25 86278910 1 WASHER, 3/8 X 7/8 FLAT SS
26 86008660 2 COTTER, 5/16 RING
27 86275470 1 SCR, 10-32 X 5/8 PPHMS SS
28 86006270 2 PIN, CLEVIS 5/16 X 1.63 PLTD
29 86271840 2 NUT, 5/16-18 HEX NYLOCK THN SS
30 86005810 4 NUT, 1/4-20 HEX NYLOCK SS
31 86005800 1 NUT, 3/8-24 HEX JAM, PLTD
32 86271240 2 NUT, CAP, PUSH, .25"
33 86270990 1 NUT, 10-32 HEX NYLOCK SS
34 86219690 4 KNOB, 1.5 OD X 5/16-18
35 86332400 2 LIFT BRKT, DOUBLE SCRUB
36 86332460 2 LANYARD ASSY, COILED CABLE
- 86338160 - SQUEEGEE ASM, CS20 KIT COMPLETE
