86333220 CS20 111
Squeegee Linkage-Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL NO
FROM
NOTES
1 86347830 1 SPRING, TORSION .048, 180 DEGREE
2 86346500 1 SHAFT, LATCH, SQUEEGEE
3 86346480 1 BRACKET, LATCH, SQUEEGEE
4 86346440 1 BRACKET, SWIVEL MOUNT
5 86325200 1 BUSHING, 30mm, BRNZ
6 86319820 1 PIVOT, SQUEEGEE LINKAGE
7 86279070 2 WASHER, M6 FLAT
8 86273850 1 SCR, 1/4-20 X 2.00 HHCS SS
9 86271870 1 NUT, 1/4-20 HEX NYLOCK THIN SS
10 86271240 2 NUT, CAP, PUSH, .25"
11 86010630 2 WASHER, 1/4 X 5/8 FLAT SS
12 86005810 2 NUT, 1/4-20 HEX NYLOCK SS
13 86347870 1 BRACKET, SQUEEGEE MOUNT
14 86327700 2 5/16 X 5/8 LG SHOULDER BOLT, SS
15 86010630 2 WASHER 1/4 ID X 5/8 OD SS
16 86271870 2 NUT, 1/4-20 HEX NYLCK THIN SS
17 86348670 1 WASHER, 1.26ID X 1.70OD X .065 THK
18 86348300 1 WEAR PAD, LIFT, SQGE
19 86351350 2 WASHER, .260 X .625 X .031, NYL, BLK
