86333220 CS20 131
Wiring-Diagram -From Serial No. *(5)
REF DESCRIPTION
F1 CIRCUIT BREAKER-BRUSH
F2 CIRCUIT BREAKER-VACUUM MOTOR
F3 CIRCUIT BREAKER-DRIVE CONTROL
G1-G3 BATTERY 12V/70Ah
H1 SIGNAL LAMPS REVERSE DIRECTION
H2 SIGNAL LAMPS DIRECTION FORWARD
H3 HORN
H4 LED-BATT.
K1 RELAYS-REVERSE DIRECTION
K2 RELAYS DIRECTION FORWARD
K3 RELAYS BRUSH MOTOR
K4 RELAYS VACUUM MOTOR
K5 REALYS ACTUATOR
K6 RELAYS MAIN
M1 BRUSH NMOTOR
M3 TRACTION MOTOR
M4 LINEAR ACTUATOR MOTOR BRUSH/SQUEEGEE
S0 EMERGENCY SWITCH
S1 KEYSWITCH
S2 MICROSWITCH-PLATFORM
S3 BUTTOM REVERSE FORWARD
S4 HORN BUTTON
S5 MICROSWITCH-COVER
S6 MIRCOSWITCH-VACUUM
S7 MICROSWITCH-BRUSH
S8 PROGRAM SWITCH
S9 MICROSWITCH-MID
S10 MIRCROSWITCH-LOWER
S11 CHARGER
S-UP-SDOWN MICROSWITCH
P1 HOURS METER
V1-V2-V3-V4-V5-V6-V7-V8-V9 DIODE
V-UP & V-DOWN DIODE-MOTOR M4
X3 TERMINAL BLOCK
FRAME X1-X2-X3-X4-X5-X6-X7 PLUG AND SOCKET
FRAME 8X-X9-X10-X11-X12 PLUG AND SOCKET
Y1 BRAKE
Y2 ELECTOVALVE WATER
