86333220 CS20 63
***86246610 AND ROTARY SWITCH ARE INCLUDED WITH CONTROL PANEL HARNESS, 98408880 IS FOR
REPLACEMENT OF THE ROTARY SWITCH WITHOUT HARNESS.
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86002010 1 BOOT, 3/8 CIRCUIT BREAKER
2 86332510 2 BOOT, SEAL PUSH BUTTON 11MM
3A 86328180 1 BREAKER, 12A, 250VAC, 32VDC DISK
3B 86349290 1 BREAKER, 25A, 250VAC, 32VDC CYLINDRICAL
4 98408880 1 KIT, CS20 ROTARY SWITCH ***
5 86316160 1 BREAKER, 18A, 250VAC, 32VDC
6 86315470 1 METER, HOUR, LCD
7 86314150 1 KNOB, SELECTOR
8 86313950 1
SWITCH, SPDT 3 POSN MOM,
ARROW
9 86295200 1 ASM, BUTTON, BLACK, W/BEZEL
10 86292780 1 SWITCH,MICRO
11 86292590 1 SWITCH, E-STOP AKW CHARIOT
12 86255900 2 STANDOFF, 6-32 X 5/8 HEX NYL
13 86246610 1 LIGHT ASM, INDICATOR ***
14 86230140 1 BREAKER, 1.5A THERMAL CIRCUIT
15 86007170 1 SWITCH, KEY 2 POSITION
16 86329570 4 SCR, 10-32 X 1.0 TORX SS BLK PLTD
17 86327830 1 GASKET, .188 X.31 X 41.0
