86333220 CS20 79
On Board Battery Charger-Deluxe & Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 98408740 1 KIT, CHARGER, SPE 36V 15A
2 86332690 1 BRKT, CHARGER METER
3 86348390 1 BRACKET, CORD STORAGE DELUXE
4 86327690 1 BRACKET, CHARGER
5 86259400 2 WASHER, THRUST .51 ID X 1 ODBRO
6 86010670 7 WASHER, 5/16 X 3/4 SS
7 86276070 5 SCR, 5/16-18 X 3/4 CARRIAGE SS
8 86006770 7 SCR, 10-32 X 1/4 PHTR PLTD
9 86006750 2 SCR, 5/16-18 X 1.00 HHCS GR5
10 86270830 5 NUT, 5/16-18 HEX NYLOCK SS
11 86345510 1
CORD, ONBOARD CHARGER, 16/3C
SJTO
12 86198450 2 CLAMP, 5/16 DIA NYLON
13 86228990 2 BEARING FLG .314IDX.5002OD
14 86333070 1 METER, SPE BATTERY CHARGE
15 86198470 5 CLAMP, 9/16 DIA NYLON
16 86333940 - BRACKET, CHARGER CORD
17 86006590 1 SCREW 10-32 X 1/2 PPHMS SS NP
18 86264940 1 CABLE TIE, 11.38" UL/CSA
