86333220 CS20 93
Scrub Deck Drive Assembly-Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 73031040 6 SCREW 5X16 -A2-70 (IN6RD)
2 50353850 1 COVER GEAR
3 63484670 2 TOOTHED BELT HTD-384-3M-20 CXPIII
4 56255060 2 BELT PULLEY 21Z
5 74011150 8 BALL BEARING 6002-2RS
6 50353840 1 CARRIER MOTOR WORKED R
7 73060890 1 SCREW M6X12 -8.8-R2R (IN6RD)
8 50354560 2 SLEEVE
9 41002440 2 SHAFT GEAR RIGHT
10 50353910 1
SHEET METAL COMPONENT COVERING
CAP INVER
11 51004810 2 DRIVESHAFT
12 51106860 2 SPACER SLEEVE
13 73432310 2 LOCKING RING 32X1,2 -ST-PH DIN 472
14 50560100 1 ROCKER BR-VS
15 56255070 2 BELT PULLEY 56Z
16 73122760 2 WASHER 6 -200HV-A2E ISO7093-1
17 73060870 2 SCREW M6X10 -8.8-R3R (IN6RD)
