WisyCom MCR54 - How to update the firmware:

MCR54 / MCR54-DUAL User Manual
25
AWS-BK-RA
Whip antenna UHF 470-700 MHz
SMA connector, black cap
Right angle
AWS-GN-RA
Whip antenna UHF 670-870 MHz
SMA connector, green cap
Right angle
AWS-BL-RA
Whip antenna UHF 820-1160 MHz
SMA connector, blue cap
Right angle
How to update the firmware:
1. Connect the MCR54 to the PC through the USB-C cable
2. Check if the version of Wisycom Manager installed in your PC is the latest version. If not,
upgrade to the new version
3. Run Wisycom Manager
4. Power up the receiver MCR54
5. Push FW UPDATE button
6. Download the .xupf file from the website and load the file using FW library > Import
button.
7. Select the file
8. Select the receiver and Play
First the program erases the flash memory and later it writes the flash memory. A green bar below
the panel shows the progress of this process. Take care do not disconnect the USB communication
or power off the MCR54 during this process.
