MCR54 / MCR54-DUAL User Manual
16
Audio Route: MCR54-DUAL
MCR54-DUAL provides two receivers and works the same as MCR54. For audio routing, the above
tables modify as follows for each rear panel.
BPA54:
TOP output
BASE#1 output BASE#2 output
1 GND
2 CHANNEL1+
3 CHANNEL1-
4 CHANNEL2+
5 CHANNEL2-
CH1
CH2
CH1
CH2
CH3
CH4
A1
A2
A1
A2
-
-
D1, D2
-
-
-
D1, D2
-
A1
A2
-
-
IKSS:
SX:
TOP output
BASE output
2 CHANNEL1
3 CHANNEL2
1 GND
2 CHANNEL1+
3 CHANNEL1-
4 CHANNEL2+
5 CHANNEL2-
CH1
CH2
CH1
CH2
A1
A2
A1
A2
D1, D2
-
TOP output
BASE output
2 CHANNEL1+
3 CHANNEL1-
15 CHANNEL2+
16 CHANNEL2-
1 GND
2 CHANNEL1+
3 CHANNEL1-
4 CHANNEL2+
5 CHANNEL2-
CH1
CH2
CH1
CH2
A1
A2
D1, D2
-
D1, D2
-
A1
A2
