witbox bq User Manual

15
ENGLISH
Attaching the spool and support
The spools of lament need to be placed on
a spool-holder. First, attach the metal
support to the rear of the printer by inserting
the short end into the corresponding slot.
Then remove the plastic protector from the
spool and place it onto the spool-holder. The
lament will be loaded at a later stage.
Connecting the power cable
Before connecting the power cable, make sure the switch is in the “0” position.
Then connect the power cable to the printer and plug the other end into the
power socket.
Caution! Handle with care

witbox bq Specifications

General

Build Volume	297 x 210 x 200 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD Card
Display	LCD
Print Technology	FDM (Fused Deposition Modeling)
Layer Resolution	50 to 300 microns
Supported Materials	PLA
Frame Material	Steel
Power Supply	100-240V, 50-60Hz
