witbox bq User Manual

7
ENGLISH
GETTING STARTED
Box contents
Before using your Witbox printer for the rst time, please check the contents of
the box. If any of the items listed below are missing, contact the retailer where
you purchased the device.
Witbox 3D printer
Print base
Set of two keys
Two side panels and one top panel
USB cable
Power cable
Spool of PLA lament (1.75 mm)
Metal spool-holder
SD card (pre-loaded with sample 3D models)
Sample printed object
Four feet/underside supports
Maintenance kit, comprising:
One replacement Hot-End
Two cleaning needles
Three Allen keys (1.5, 2.5 and 4 mm)

witbox bq Specifications

General

Build Volume	297 x 210 x 200 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD Card
Display	LCD
Print Technology	FDM (Fused Deposition Modeling)
Layer Resolution	50 to 300 microns
Supported Materials	PLA
Frame Material	Steel
Power Supply	100-240V, 50-60Hz
