CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
4.1.t
Subject to change without notice! Soggetto a modifica senza preavviso!
THREE PANELS TELESCOPIC CAR DOOR, TYPE 35/R-L PL=600÷1400
PORTA DI CABINA TELESCOPICA 3 ANTE, TIPO 35/R-L PL=600÷1400
STANDARD OPERATORS SEMI-REINFORCED OPERATORS
OPERATORI STANDARD OPERATORI SEMI-RINFORZATI
PL C D D1 D2 GW WS
GM
PGM P
600 825 825 875 920 875 920
650
228 695 /
891 885 925 970 925 970
700 958 930 975 1020 975 1020
750 250 1025 1000 1025 1070 1025 1070
800
/
1091 1060 1100 1145 1100 1145
850 912
217
1158 1130 1150 1195 1150 1195
900 1225 1200 1225 1270 1225 1270
950
325
1291 1250 1275 1320 1275 1320
1000 1358 1330 1325 1370 1325 1370
1050 1425 1400 1375 1420 1375 1420
1100 400 1137
225
1491 1450 1425 1470 1425 1470
1150 1558 1530 1560 1605 1560 1605
1200 / 1625 1600 1610 1655 1610 1655
1250 475 1300 287 1691 1650 1660 1705 1660 1705
1300 1758 1730 1710 1755 1710 1755
1350 1825 1800 1825 1870 1825 1870
1400
550 1362 225
1891 1850 1875 1920 1875 1920
*
*
ATTENTION: GM
> GW
ATTENZIONE: GM
> GW
*
FOR GLASS DOORS AND GLASS-FRAMED DOORS
ALWAYS USE REINFORCED OPERATORS
PER PORTE CON ANTE IN VETRO E VETRATE
CONSIDERARE SEMPRE OPERATORI RINFORZATI
PL (1) (2)
600 85 120
650 86 122
700 87 124
750 88 127
800 90 130
850 94 136
900 98 141
950 99 143
1000 105 151
1050 108 155
110 0 111 1 60
1150 114 164
1200 116 168
1250 117 170
1300 119 173
1350 124 180
1400 125 182
WEIGHTS FOR DOORS WITH STANDARD AND DOUBLE SKIN PANELS
PESI PER PORTE CON ANTE STANDARD E TAMBURATE
WEIGHTS FOR DOORS WITH GLASS AND GLASS-FRAMED PANELS
PESI PER PORTE CON ANTE IN VETRO E VETRATE
(2)
(1)
CAR DOOR TOTAL WEIGHT
PESO TOTALE PORTA DI CABINA
kg
LH=2000
