CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
4.2.t
Subject to change without notice! Soggetto a modifica senza preavviso!
THREE PANELS TELESCOPIC CAR DOOR, TYPE 32/R-L PL=600÷2100
PORTA DI CABINA TELESCOPICA 3 ANTE, TIPO 32/R-L PL=600÷2100
SEMI-REINFORCED OPERATORS
PESO TOTALE STANDARD OPERATORS OPERATOR SEMI-RINFORZATI
TOTAL WEIGHT OPERATORI STANDARD REINFORCED OPERATORS
OPERATOR RINFORZATI
PL
LH=2000
C C1 D D1 D2 GW WS
GM
PGM P
600 85 825 825 880 925 880 925
650 86
228 695 /
891 885 930 975 930 975
700 87 958 930 980 1025 980 1025
750 88 250 1025 1000 1030 1075 1030 1075
800 90
/
1091 1060 1101 1146 1107 1152
850 94 912
217
1158 1130 1151 1196 1157 1202
900 98 1225 1200 1216 1261 1232 1277
950 99
325
/ 1291 1250 1266 1311 1282 1327
1000 105 1358 1330 1316 1361 1332 1377
1050 108 1425 1400 1366 1411 1382 1427
1100 111 400 1137
225
1491 1450 1416 1461 1432 1477
1150 114 1558 1530 1551 1567 1612
1200 116 1625 1600 1601
1596
1662 1662
1250 117 475 1300 287 1691 1650 1651 1667 1712
1300 119 1758 1730 1701
1655
1717 1762
1350 124 1825 1800 1816 1832 1877
1400 125
550 1362
/ 1891 1850 1866
1755
1882 1927
1450 147 438 438 1958 1930 1932 1977
1500 158 450 450 2025 2000 1982 2027
1550 159 463 463
1207
2091 2050 2032 2077
1600 161 475 475 2158 2130 2082 2127
1650 162 488 488 2225 2200 2132 2177
1700 165 500 500 2291 2250 2182 2227
1750 167 513 513 1307
225
2358 2330 2232 2277
1800 177 450 450 2425 2400
/
2432 2477
1850 180 460 460 2491 2450 2482 2527
1900 200 470 470 2558 2530 2532 2577
1950 202 480 480 2625 2600 2582 2627
2000 204 490 490 1382 2691 2650 2632 2677
2050 205 500 500 2758 2730 2682 2727
2100 207 510 510 2825 2800 2732 2777
ATTENTION: GM > GW
ATTENZIONE: GM
> GW
*
FOR GLASS DOORS AND GLASS-FRAMED DOORS
ALWAYS USE REINFORCED OPERATORS
PER PORTE CON ANTE IN VETRO E VETRATE
CONSIDERARE SEMPRE OPERATORI RINFORZATI
PL
600
650
700
750
800
850
900
950
1000
1050
110 0
1150
1200
1250
1300
1350
1400
1450
1500
1550
1600
1650
1700
1750
1800
1850
1900
1950
2000
2050
2100
*
*
*
*
*
PL (1) (2)
600 85 137
650 86 140
700 87 143
750 88 146
800 90 150
850 94 156
900 98 162
950 99 166
1000 105 174
1050 108 179
110 0 111 1 84
1150 114 189
1200 116 193
1250 117 196
1300 119 201
1350 124 208
1400 125 211
1450 147 235
1500 158 240
1550 159 243
1600 161 248
1650 162 251
1700 165 256
1750 167 261
1800 177 272
1850 180 277
1900 200 282
1950 202 285
2000 204 289
2050 205 292
2100 207 295
WEIGHTS FOR DOORS WITH STANDARD AND DOUBLE SKIN PANELS
PESI PER PORTE CON ANTE STANDARD E TAMBURATE
WEIGHTS FOR DOORS WITH GLASS AND GLASS-FRAMED PANELS
PESI PER PORTE CON ANTE IN VETRO E VETRATE
(2)
(1)
CAR DOOR TOTAL WEIGHT
PESO TOTALE PORTA DI CABINA
kg
LH=2000
A
B
C
