Variants Max. 0.6A Max. 2.4A Max. 9A
General data
Power dissipation min. / max. 0.88W / 2.8W 0.88W / 5.5W 0.88W / 12W
Max. switching frequency (pulse / pause times 50:50) 2Hz
Deactivation time via control supply voltage type 25ms max. 500ms
Deactivation time via activation voltage type 30ms max. 80ms
Activation time via activation voltage type 40ms max. 50ms
Rated surge voltage between control input, control supply
and switching voltage
Nominal mains voltage (≤ 500V AC)
Nominal mains voltage (≤ 300V AC), e. g. 230 / 400V AC,
277 / 480 V AC
Nominal mains voltage (≤ 300 – 500V AC)
6kV
Safe isolation (EN 50178)
Safe isolation (IEC 60947-1)
Basic isolation (IEC 60947-1)
Control input, control supply voltage and reply output,
reply output and switching voltage
Nominal mains voltage (≤ 500V AC)
Nominal mains voltage (≤ 300V AC), e. g. 230 / 400V AC,
277 / 480V AC
Nominal mains voltage (≤ 300 – 500V AC)
Safe isolation (IEC 60947-1)
Safe isolation (EN 50178)
Safe isolation (IEC 60947-1)
Basic isolation (IEC 60947-1)
Ambient temperature range operation
Ambient temperature range transport, storage
– 25°C – + 70°C
– 40°C – + 80°C
Surge voltage category III
Pollution degree 2
Standards/specifications
Power station requirement
IEC 60947-4-2 / IEC 61508-1 / ISO 13849-1/EN 954-1
DWR 1300 / ZXX01/DD/7080.8d
Service life 3 × 10
7
cycles
Degree of protection IP20
Mounting position Vertical (horizontal DIN rail / busbar)
Mounting (see 9. Derating curve) Can be mounted in rows with zero spacing or with ≥ 20mm spacing
Housing:
Material
Dimensions incl. DIN rail adapter
Dimensions incl. power busbar adapter 30Compact
Dimensions incl. power busbar adapter 60Classic
PA 6.6
(22,5 / 175 / 138)mm (W/H/D)
(22,5 / 160 / 156)mm (W/H/D)
(22,5 / 200 / 156)mm (W/H/D)
Connection data (conductor cross-section)
Screw terminal blocks (solid / stranded)
M3 thread, recommended torque
See connection notes (page 22)
0.14 – 2.5mm²
0.5 – 0.6Nm
AWG 26–14
4.4 – 5.3 lb-in
Adapter connection data
Connection Ø DIN rail adapter (solid / stranded)
Copper Ø Compact / Classic power busbar
Max. power busbar current
0.2 – 6mm² / 0.2 – 4mm² (AWG 24–10)
5 (or 10) × 12mm / 5 (or 10) × 30mm
2500A
Weight
DIN rail adapter
6Power busbar adapter 30Compact
Power busbar adapter 60Classic
Approx. 368g
Approx. 374g
Approx. 377g
Certification EX II (2) G [Exe] [Exd] [Expx] EX II (2) D [Ext] [Exp]
EC type examination certificate to ATEX PTB 13 ATEX 3001
Safety level See section 8.1 and 8.2
