Wolf CGB-75 - Conversion to Other Gas Types (if Required)

313062555_201804
16.Conversiontoothergastypes(ifrequired)
Note: DuringtheconversionfromnaturalgastoLPG,auegasoriceplatemustalsobeinstalledinthecondensatepanas
follows.DuringconversionfromLPGtonaturalgas,theuegasoriceplatemustberemoved.
Thisinstallationstepiscarriedoutpriortotheinstallationofthemixingchamberandfullassembly.
Slidethebalanceduelockingmechanisminthedirection
ofthearrow.Pulltheuepipeupoutofthecondensatepan.
9)
11)
Updating the type plate
Cut out the relevant lines from the type plate supplied
andafx themover the relevantlines on theappliance
type plate.
Conversion type plate Fig.: Updating the type plate
After removing the upper casing cover, undo the self-tap-
pingscrewatthebalanceduelockingmechanism.
8)
Conversion sets for CGB-75/100 for conversion to other gas types: (Please state the corresponding part number when ordering)
ConversiontonaturalgasE/H(G20) ID 1000*
Conversion to natural gas LL** (G25) ID 1260*
Conversion to LPG P*** (G31) ID 6.7*
ConversionfromLPGP(G31)tonaturalgasE/H(G20) ID 1000*
Conversion from LPG P (G31) to natural gas LL** (G25) ID 1260*
* ID imprinted on gas restrictor
** Natural gas LL and E are not applicable for Austria / Switzerland
*** LPG not applicable for Switzerland
PlacetheuegasoriceplateØ53mmintothecondensate
panandinserttheuepipeagain.
Note: During conversion from LPG to natural gas, the
uegasoriceplatemustberemoved.Fitthe
mixing chamber as described under point 6).
Re-assemble in reverse order.
10)
Fluegasoriceplate
