Minimumductsizes
applicabletoopenueandroomsealedoperation
Air/uegasrouting,rigidinashaft
Min.ductsizes
CircularØ
Rectangular
DN 110
DN160
190 mm
250 mm
170 mm
230 mm
4
>20
>30
5
C93x room sealed in a duct
DN 110
C33xbalancedue
in a duct DN 110/160
B33openue
in a duct DN 110
C93x room sealed
System DN 110/160
horizontal and DN 110
vertical
B33
