INTRODUCTION
The major components of the moulder
INTRODUCTION 15doc042320 1-3
1
FIG. 1-0 MP150
WMM085
Moulding Head
Electrical
Box
Control
Panel
Head Height
Scale
Up/Down
Drive
Power Feed
Drive (optional)
