PLANER/MOULDER SPECIFICATIONS
Specifications of the planer/moulder
5
5-7 EGdoc021023 Specyfikacje
See table 5-7. Feed rate
See table 5-8. The noise level generated by Wood-Mizer planer/moulder is given in the table below
1
2
3
IMPORTANT! The total value of hand-arm vibration the operator may be
exposed to does not exceed 2.5 m/s
2
. The highest root mean square value
of weighted acceleration to which the whole operator’s body is subjected
does not exceed 0.5 m/s
2.
See table 5-9. See the table below for planing/moulding material specifications
Planer/moulder type Feed Rate
MP200EH6S
(Constant Feed Speed)
5 m/min
MP200EH6S
(Adjustable Feed Speed)
2-12 m/min
TABLE 5-7
Noise Level
Planer/Moulder MP200
Equipped with electric motor
L
pA
= 86dB (A)
L
WA
= 104dB (A)
TABLE 5-8
1. The noise level measurement was taken in accordance with PN-EN ISO 3746 Standard . Value for associated
uncertainty K=4dB.
2. The measured values refer to emission levels, not necessarily to noise levels in the workplace. Although there is
a relation between emission levels and exposure levels, it is not possible to determine with certainty if preventives
are needed or are not needed. Factors that influence the actual level of exposure of the workforce include the
characteristics of the work room and the other sources of noise etc. i.e. the number of machines and other adjacent
processes. Also, the permissible exposure level value may vary depending on country. This information enables
the machine’s user to better identify hazards and a risk.
3. The total value of hand-arm vibration the operator may be exposed to does not exceed 2.5 m/s
2
. The highest
root mean square value of weighted acceleration to which the whole operator’s body is subjected does not exceed
0.5 m/s
2
.
One-sided planing Double-sided planing
Minimum Cant Height 15 mm 15 mm
Maximum Cant Height 210 mm 100 mm
Minimum Cant Width 10mm 10mm
Maximum Cant Width 410 mm 300 mm
TABLE 5-9
