Manual 37240C GCP-30 Series - Genset Control
Chapter 1.
General Information
Type English German
GCP-31/32 Series
GCP-31/32 Packages - Installation 37364 GR37364
GCP-31/32 Packages - Configuration 37365 GR37365
GCP-31/32 - Function/Operation 37238 GR37238
GCP-31/32 - Application this manual Ö 37240 GR37240
Option SB 37200 GR37200
Option SC06/SC07/SC08 37313 GR37313
Option SC09/SC10 37382 GR37382
Additional Manuals
IKD 1 - Manual 37135 GR37135
Discrete expansion board with 8 discrete inputs and 8 relay outputs that can be coupled via the CAN bus to the control unit. Evalua-
tion of the discrete inputs as well as control of the relay outputs is done via the control unit.
LeoPC1 - Manual 37146 GR37146
PC program for visualization, for configuration, for remote control, for data logging, for language upload, for alarm and user man-
agement and for management of the event recorder. This manual describes the use of the program.
LeoPC1 - Manual 37164 GR37164
PC program for visualization, for configuration, for remote control, for data logging, for language upload, for alarm and user man-
agement and for management of the event recorder. This manual describes the programming of the program.
GW 4 - Manual 37133 GR37133
Gateway for transferring the CAN bus to any other interface or bus.
ST 3 - Manual 37112 GR37112
Control to govern the air fuel ratio of a gas engine. The ratio will be directly measured though a Lambda probe and controlled to a
configured value.
Table 1-1: Manuals - Overview
Intended Use The unit must only be operated in the manner described by this manual. The prerequisite for a
proper and safe operation of the product is correct transportation, storage, and installation as well as careful op-
eration and maintenance.
NOTE
This manual has been developed for a unit fitted with all available options. Inputs/outputs, functions,
configuration screens, and other details described, which do not exist on your unit, may be ignored.
The present manual has been prepared to demonstrate different applications of the unit. The descrip-
tion of the applications assumes that you are familiar with the unit and the described peripheral de-
vices and have read the manuals belonging to them. You can refer to the respective manuals for infor-
mation about operation and configuration of the unit and the peripheral devices.
Page 4/38 © Woodward
