LF 170 Operation
97
ba54104e09 11/2010
skipped.
z From any point of the main level press <ESC> to return to the
starting point of the parameterization level. From here change to the
operating level with <M> or <ESC> or to the configuration level with
<UP><DOWN>.
z From any point of the main level press <M> to also go directly to the
operating level.
z In view mode you can change to the operating level from any point
with <M>.
Setting table:
Setting Selection/Values Explanation
(values in bold typeface = values on delivery)
PR1 z 4
:
20
z 0
:
20
or
dI
:
=1 ... dI
:
20
Current range and attenuation of the REC 1
current output in rEC operating mode
(analog output).
Operating notes:
– The setting is carried out in the order:
current range -> attenuation
– Press 1x <ENTER> in between.
The following values can be set:
z Current range:
– 4 to 20 mA, or
– 0 to 20 mA
z "dI" = attenuation dI/dt (in mA/s):
–0.1
–1
–5
–20
Attenuation is the change speed of the
current signal in the case of erratic
changes of the input signal.
PR2
(only with RT and
RT RS option)
z 4
:
20
z 0
:
20
or
dI
:
=1 ... dI
:
20
Current range and attenuation of the REC 2
current output in rEC operating mode
(analog output).
For setting possibilities, see Pr1 (ReC
operating mode).
