Operation LF 170
98
ba54104e09 11/2010
PL
UL / LL REL 1/2
HS
tD
(only with RT and
RT RS option)
(depending on the
configuration)
Settings for the REL 1 and REL 2 relays
configured as limit indicators.
The parameterization of the limit indicator is
described in detail in section 4.6.
The REL 1 or REL2 status display shows for
which relay the setting has just been made.
PIF
(only with RT RS
option)
(depending on
master/slave
operating mode)
Interface parameter (Baud rate, address
etc.).
The parameterization of the RS 485 interface
is described in a separate manual that is
included in the scope of delivery of the
instrument variant with RS 485 interface
(RT RS option).
PCd 000 ... 999 Password against unintentional changes of
configuration and parameterization.
000 = password protection is deactivated
(state on delivery)
Operating note:
– Set the first (flashing) digit with
<UP><DOWN> and confirm with
<ENTER>.
– Set the other digits in the same way.
Notes:
After setting up password protection
the instrument can only be configured and
parameterized after entry of the correct
password. The password "555" is not
permissible.
Setting Selection/Values Explanation
(values in bold typeface = values on delivery)
