<ENTER> – Key
Function – 1 –
The key <ENTER> is used for saving data or for confirming taken actions.
Function - 2 -
In connection with the software LEVELSOFT PRO and MT-SOFT the key is used for
collecting the actual measured value.
Function – 3
The key <ENTER> is used for turning on resp. turning off the backlight in the display
<SEND/ESC>- Key
Function - 1 -
Using the key <SEND/ESC> will send the displayed value to a port of a connected PC,
or Laptop. It is recommended to use the infrared zapper instead of the <SEND/ESC>
key.
OUT-port data format
MeasuringMode_A [sss xxxxxx sn.nnnnnn<cr>]
MeasuringMode_B [sss xxxxxx sn.nnnnnn<cr>]
MeasuringMode_A_minusB [sss xxxxxx - xxxxxx sn.nnnnnn<cr>]
MeasuringMode_A_B [sss xxxxxx sn.nnnnnn xxxxxx sn.nnnnnn<cr>]
sss = 0 .. 255 - Sequence number
xxxxxx = Sensor Serial Number and Type
H4001B BlueLEVEL or BlueLEVEL BASIC
H4001C +CLINO PLUS+
H4001M MINILEVEL NT
H4001Z ZEROTRONIC Sensor
H4001x ZEROMATIC 2/1 X - Axis
H4001y ZEROMATIC 2/1 Y - Axis
H4001X ZEROMATIC 2/2 X - Axis
H4001Y ZEROMATIC 2/2 Y - Axis
sn.nnnnnn = +9.999999 - Positive Overrange
-9.999999 - Negative Overrange
Measured value - Angle in rad e.g. +0.226349
Data transmission format:
asynchron, 7Bit, 2 Stopbits, no parity
Function - 2 -
Delete the "HOLD" function and return to the mode MEASURE.
Function - 3 -
Cancel the functions of the various menus
