APPENDIX
A BASICS AND GENERAL REMARKS ABOUT BLUESYSTEM BASIC AND INCLINATION MEASUREMENT
A1 I
NTRODUCTION TO THE BLUESYSTEM BASIC
The new
BlueSYSTEM BASIC series
has been developed as a basic model to the well known and well proven
measuring instruments of the BlueSYSTEM family with wireless data transmission. Compared to the existing
systems with wireless data transmission the BlueSYSTEM BASIC series has an excellent price/performance ratio
and is easier to operate.
The BlueSYSTEM BASIC is available with wireless data transmission or cable transmission
. It is, however,
possible to upgrade the system without wireless data transmission at a later stage by WYLER to use Bluetooth™
wireless technology.
As its predecessor this newest generation of high precision electronic inclination measuring instruments is
specifically suitable for the precision measurement of smallest angles. Applications are therefore in particular the
measurement of flatness of surface plates or the measurement of the geometry of machine tools. The sensor itself,
the heart of every precision measuring instrument, has been further developed as well, to allow precise
measurements even under critical environmental conditions.
The key features of these new series of instruments are:
• Compact and pleasant new design which is functionally optimized for precision measurement
•
Wireless data transmission using the internationally recognised Bluetooth™ wireless technology
(optional)
• Complete new sensor design
• Sensor as well as amplifying electronic fully sealed and encapsulated in inert gas
• Increased temperature stability
• Increased long term stability
• Large and well readable LCD display on the BlueMETER BASIC
• Recognition of the specific instrument’s address and shown in display of BlueMETER BASIC
• Correct assignment of an instrument
• Activate measurement via IR through the BlueMETER BASIC or one of the BlueLEVEL BASIC
• Compatible to existing measuring bases
• One range only in every instrument
• There are three different BlueLEVEL BASIC types available
o BlueLEVEL BASIC 1 µm/m: Range ±10mm/m
o BlueLEVEL BASIC 5 µm/m: Range ±50mm/m
o BlueLEVEL BASIC 10 µm/m: Range ±100mm/m
• Linearity throughout the measuring range according to DIN 2276
• All instruments are equipped with RS 232 / RS 422 / RS 485 interfaces
• Powered by standard 1.5 V batteries type “C”
• In compliance with CE regulations
The new measuring instruments of the BlueSYSTEM BASIC family can must be used in combination with a display
instrument, e.g. with a BlueMETER BASIC, or can be used combined in a set (2 BlueLEVEL BASIC and
1 BlueMETER BASIC).
A set of instruments, also called ENGINEER SET, normally consists of one or two BlueLEVEL BASIC and one
BlueMETER BASIC, forming the ideal tool for measuring flatness and machines under work shop conditions.
Furthermore the ENGINEER SET can be used for any levelling task or analysis of rotations.
