The ENGINEER SET is specifically adapted to the needs of the metrology specialist taking care of machine tool
components. There is a broad range of applications due to the possibility to use differential measurement. The
system is universally applicable for inclination and for rotational measurements Thanks to its outstanding features
and to the special transportation case the ENGINEER SET can be used in-house or be taken along to customers.
A2 INSTRUMENT’S OVERVIEW
THE INSTRUMENTS OF THE BLUESYSTEM BASIC - FAMILY IN DETAIL
The following instruments are part of the BlueSYSTEM family
BlueLEVEL BASIC
The measuring instrument with different sensitivities
available
BlueMETER BASIC
Display unit with various functions also serving as
interface between PC/Laptop. The BlueMETER Basic
is available only without radio module.
Common features of all the BlueSYSTEM BASIC family instruments:
• One international standard in Bluetooth™ wireless technology, if equipped with the radio modules
• All instruments are equipped with RS232 / RE422 / RS485 interfaces
• All instruments compatible to WY-BUS (RS485+)
• All instruments working equivalently on the same level of communication
Additional features only available in the BlueMETER BASIC:
Additional functional keys for:
o Choice of sensor connections A or B, A and B, A minus B
o Refresh function in order to up-date the list of instruments
o Install relative ZERO
o HOLD Function, e.g. for "freezing" a measured value.
o Display of the measured value of one or two instruments connected
o Display of the difference between two connected instruments
o Change of display unit using mm/m (µm/m) or Arcsec
o Set various filter types
