Battery indicater
"BATT"
BlueMETER BASIC
Usually the actual battery power is displayed. E.g. 4
2
(4.2 Volt)
Regarding the status indication of the internal power the following options
are possible:
Usually the actual battery power is displayed, e.g. 36 (3.6 Volt)
Regarding the status indication of the internal power the following options
are possible:
Note: The internal voltage U
INT
must not be confused with the
Battery voltage U
BATT
respectively the external supply voltage U
EXT
!
External Power Supply U
EXT
Battery supply U
BATT
Indication with sufficient voltage
U
INT
> 4,75V
Indication with sufficient voltage
U
INT
> 4,75V
Supply voltage U
INT
<4.75V
Supply voltage U
INT
<4.75V
Attention:
The following indications refer to the status of the supply voltage in the measuring
instruments which are connected to the BlueMETER; e.g. BlueLEVEL. Instead of a
measuring value the following symbols are displayed. These symbols indicate that it
is no longer possible to acquire or transmit any values!
Supply voltage in the external
Instrument U
INT
< 4.5V
Measuring no longer possible
Supply voltage in the external
Instrument U
INT
< 4.5V
Measuring no longer possible
