Xantrex BC3012 User Manual

Error Messages on Optional Remote Display
975-0188-01-01 3–5
Err
CLd
Red fault indicator light
illuminated
Green 10% indicator light
flashes
Green bank indicator light for
affected battery bank
illuminated
Battery Too
Cold
Shutdown
Allow batteries to warm up before
attempting to charge again. Charging a
battery that has frozen is a potential
explosion hazard.
DIS 25% current indicator light
flashes
Battery
Disqualified
Warning
Wait 15 minutes for the next battery
detection cycle. The warning may be
temporary.
Verify that the battery meets the minimum
AmpHour rating (BC1524: 30 Ah,
BC2524: 50 Ah, BC3012: 60 Ah,
BC5012: 100 Ah)
Try adding a small DC load.
Replace the battery.
HI Green bank indicator light for
the affected battery bank
illuminated
Over Voltage
Shutdown
Warning
Check battery. Do not charge a battery
rated at more than 12 volts nominal
(BC3012, BC5012) or 24 volts nominal
(BC1524, BC2524).
Disconnect or turn off other charging
sources such as the alternator or the
charger on a generator with electric start.
If the warning level escalates without
being corrected, the BC Series enter the
fault level and stop charging the affected
bank.
Err
HI
Red fault indicator light
illuminated
Green bank indicator light for
the affected battery bank
illuminated
Over Voltage
Shutdown
Check battery. Do not charge a battery
rated at more than 12 volts nominal
(BC3012, BC5012) or 24 volts nominal
(BC1524, BC2524).
Disconnect or turn off other charging
sources such as the alternator or the
charger on a generator with electric start.
Table 3-2 Error Messages
Display
Onboard Status Panel
Indicator lights Fault Solution
