106 Freedom SW Owner’s Guide
Specifications
NOTE: All transfer specifications are at nominal conditions: ambient temperature of 77 °F (25 °C), 120 VAC, 60 Hz input, unless otherwise specified.
Supported AC input types Single input (up to 30 amps) Split phase (up to 30 amps per line)
Dual input (up to 30 amps per line)
Transfer and General Specifications
All Models
Transfer time—utility to invert < 20 ms
Minimum AC input voltage for transfer 85 VAC
Maximum AC input voltage for transfer 135 VAC
Minimum AC input frequency for transfer 45 Hz
Maximum AC input frequency for transfer 70 Hz
Cooling Fan-cooled, temperature controlled.
Regulatory Approvals All Models
Safety CSA 107.1,
UL 458 5th Ed. with marine supplement,
ABYC E11 - Alternating Current and Direct Current Electrical Systems on Boats, and
ABYC A31 - Battery Chargers and Inverters.
EMC FCC Part 15, Class B
Industry Canada ICES-003, Class B
FSW Owners Guide.book Page 106 Tuesday, August 7, 2018 9:03 AM
