Configuring the Freedom SW using the SCP
Figure 26 Menu Map of the Freedom SW Advanced Settings 2
FSW3012 00: Setup
Mode
Battery
Load
AC In
Advanced Settings
Inverter
Search Mode
Charger
Force Chg State
Equalize
Desired Mode
Clear Faults Warnings
View Device Info
Invert
11.8V -88.0A N/A
915W 120V 7A
0V 0A 0Hz
[Enabled]
[Disabled]
[Disabled]
[Disabled]
[Standby]
StatusConfigurable Settings
FSW3012 00: Dev Info
View Fault Log
View Warning Log
View Event Log
FSW3012 00: Adv Settings
Inverter Settings
Charger Settings
AC Settings
GEN Support
Stacking
Restore Defaults
Adv Features
FSW3012 00: ACIn Settings
ACIn Breaker
ACIn Lo Volt
ACIn Hi Volt
ACIn Lo Freq
ACIn Hi Freq
[30A]
[95V]
[135V]
[55Hz]
[65Hz]
[*Enabled] [Disabled]
[*Disabled] [Enabled]
[*Disabled] [Enabled]
[*No Float] [Float] [Bulk]
[Disabled]
[*Standby] [Operating]
FSW3012 00: GEN Support
GenSup Mode
GenSup Amps
[Disabled]
[30A]
[*Disabled] [Enabled]
FSW3012 00: Stacking
Dev Name
Dev Number
Stack Mode
AC In
Battery
[00]
[01]
[Master]
[SHORE1]
[Batt1]
[*Master] [Slave] [L2Master]
[*SHORE1] [SHORE2 to 5] [GEN1 to 5] [None]
FSW3012 00: Adv Features
StoreInvState [Disabled]
[*Disabled] [Enabled]
