60 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
Table 11 Charger Settings Menu Description
Item Description
Batt
Type
Sets the system battery chemistry and type:
Flooded, AGM, Gel, and Custom.
Selecting Custom displays the Custom Settings
item, which allows you to adjust the settings for
each charging stage.
Custom
Settings
Displays the Custom Battery Settings menu,
where you can adjust settings specific to your
battery type and installation. It is only displayed if
Custom is selected as the Batt Type.
Batt
Capacity
Selects the system battery capacity in amp hours.
Setting the battery capacity to 0 resets the charging
current to its default values. Zero Ah battery
capacity implies there is no absorption exit current
criteria and absorption only exits when the
absorption timer (default 3hrs, range 1min-8hr)
expires.
Max Chg
Rate
Sets the percentage of the maximum DC output
current that is available to the charger. The
maximum DC output current for different models
is:
Freedom SW 2012 —100 ADC
Freedom SW 3012 —150 ADC
Freedom SW 2024 —50 ADC
Freedom SW 3024 —75 ADC
If two Freedom SWs are charging the same battery
bank, set each inverter's Max Chg Rate to 1/n of
the desired charge rate (where n is the number of
inverter/chargers).
Charge
Cycle
Sets the charging method: 3Stage (bulk,
absorption, float) or 2StgNoFloat
(bulk, absorption, no float).
ReCharge
Volts
Sets the recharging volts to tell the charger to
initiate charging when the battery drains past the
value setting.
Auto
ReCharge
Enables or disables automatic charging. When there
are two or more power sources for charging
batteries, Auto ReCharge can be disabled to allow
manual charging of batteries.
Table 11 Charger Settings Menu Description
Item Description
