97-0019-01-01 65
Configuring the Freedom SW using the SCP
Table 15 ACIn Settings Menu Description
Item Description
AC1
Breaker
Sets the AC1 (Grid) breaker size, based on the size
of the breaker installed on AC1. The installed
breaker size must not exceed the capacity of the
upstream distribution panel. The Freedom SW
limits the maximum input current to this setting by
derating its charging current to an equivalent of
80% of the AC breaker size. If the connected loads
exceed the AC1 breaker setting, the AC breaker
trips.
AC1 Lo
Volt
Minimum acceptable input voltage level from the
utility mains.
NOTE: It is recommended to leave this setting to its
default value and not to set it to the maximum
allowed. Doing so might inadvertently derate
charging power in jurisdictions where the nominal
AC mains voltage or generator output is at 110
volts.
AC1 Hi
Volt
Maximum acceptable input voltage level from the
utility mains.
AC1 Lo
Freq
Minimum acceptable utility mains input frequency.
AC1 Hi
Freq
Maximum acceptable utility mains input frequency.
Table 15 ACIn Settings Menu Description
Item Description
FSW Owners Guide.book Page 65 Tuesday, August 7, 2018 9:03 AM
