Xantrex RV2012GS - Battery Temperature Sensor (BTS)

Accessories
975-0209-01-01 1–5
Use only Xantrex-recommended accessories. Remote cables are available in three
lengths:
Battery Temperature Sensor
The battery temperature sensor (BTS) allows the inverter/charger to monitor the
battery temperature and adjust charging voltage according to the temperature. The
BTS can extend the life of a battery by preventing overcharging in warm
temperatures and undercharging in cold temperatures.
The BTS attaches to a battery terminal post or to the side of the battery using a
self-adhesive backing.
Part number Cable Length
31-6257-00 25 feet
31-6262-00 50 feet
31-6275-00 70 feet
Table 1-3
Part number Details
130-0004-01-01 15 foot cord, surface mount only
130-0004-02-01 25 foot cord, surface mount only
130-0004-03-01 35-foot cord, surface mount only
808-0231 25-foot cord, surface or terminal mount (shown in Figure 1-3)
Figure 1-3 Battery Temperature Sensor (808-0231)
Connector
25 foot (7.6 m) cord
Sensor
