Installation
2–4 975-0209-01-01
Wiring the Inverter/Charger
For a successful installation, you need to plan the AC and DC wiring, as well as
the remote control and generator connections. These connections are described in
this section and illustrated in Figure 2-1.
AC components include:
• Sources of AC input
•AC wiring
• Over-current protection and disconnect devices
• AC distribution panels
DC components include:
• Sources of DC power (batteries, for example)
• DC cables
• DC over-current protection and disconnect devices
• DC load center
WARNING: Fire, shock, and energy hazards
Make sure all AC and DC wiring being connected to the RS is disconnected (physically or
by opening the breaker) from all electrical sources before handling. All wiring must be
done in accordance with local and national electrical wiring codes. Xantrex recommends
all wiring be done by a qualified installer or electrician.
