Operation
3–10 975-0209-01-01
LED Indicator
Charger activity The RV Series Inverter/Charger has a three-color LED that indicates the activity
of the battery charger. The optional RC/GS or RC7 remote allows custom control
over the charger section of the inverter, including battery type.
Inverter activity In addition to indicating charger activity, the three-color LED reports on inverter
activity and error conditions.
Table 3-1
LED color and Charger Activity
LED color LED behavior Charger Activity
Orange Solid Bulk charging
Orange Flashing Absorption charge
Green Fast flashing (four times per second) Float charge
Orange Flashing Equalization charge
Table 3-2
LED color and Charger Activity
LED color LED behavior Inverter Activity
Green Solid Inverting
Green Slow flashing (once per second) Search Mode
Red Solid Over current condition
Red Flashing Error condition
