Specifications
A–2 975-0209-01-01
Electrical Specifications
Environmental Specifications
RV2012GS RV2512GS RV3012GS
Continuous Power @ 25°C 2000 watts 2500 watts 3000 watts
Max AC Current 16.6 amps 20.8 amps 25 amps
Efficiency 94% Peak
Input Current: Search Mode 0.055 amps 0.070 amps 0.080 amps
Input Current: Full Voltage 0.550 amps 0.600 amps 0.650 amps
Input Current: At Rated Power 200 amps 250 amps 300 amps
Input Current: Short Circuit 600 amps 800 amps 900 amps
Minimum input AC Voltage 40 Vac
Nominal Input Voltage 12 Vdc
Input Voltage Range 10.5–15.5 Vdc
Voltage Regulation—Maximum ±5%
Voltage Regulation—Typical ±2.5%
Output Waveform Modified sine
Power Factor allowed -1 to +1
Frequency Regulation 60Hz ± .04%
Standard Output Voltage 120 Vac
Adjustable Search Sense Range 20 to 50 watts
Forced Air Cooling Variable Speed
Automatic Transfer Relay 50 amps at 120/240 Vac split phase or 30 amps at 120 Vac single/dual input
(field configurable)
Adjustable Charge Rate 10–100 amps 10–120 amps 10–140 amps
Number of Charging Profiles 3 (GEL Cell, Flooded lead acid, AGM)
Three-Stage Charging Yes
Operating ambient temperature 0 ° – 50 °C (32 ° – 122 °F)
Non-operating temperature -55 ° – 75 °C (-67 ° – 167 °F)
