Installation
2–6 975-0402-01-01
This guide for use by qualified installers only
When planning to install the Truecharge™ 2 Battery Charger,
be sure that you consider the location and orientation
carefully. The Truecharge™ 2 Battery Charger is considered
to have an IP rating of IP-32, if installed in either of two
specific orientations [shown in Figure 2-2 a) and b)]. This
rating means that it meets standards to prevent dripping water
from entering the enclosure, and causing shock hazard and
damage to equipment.
The other possible mounting orientations will not prevent the
entry of dripping water, and are not suitable for marine or
other moist environments without the installation of
additional drip protection. They are only acceptable for use in
locations that are always dry [shown in Figure 2-2 c) and d)].
The environment, therefore, will determine the mounting
orientations that are suitable for each installation. Is the
installation environment one that will always be dry or will
moisture or condensation sometimes enter the area?
WARNING: Shock hazard
In marine environments, there is a likelihood that condensation will
be present, and may drip on to the charger. Use the appropriate
mounting orientations as shown in Figure 2-2.
