4 - 29
Working Orientation
Some bar codes are direction-sensitive. For example, KIX codes and OCR can
misread when scanned sideways or upside down. Use the working orientation
settings if your direction-sensitive codes will not usually be presented upright to
the scanner.
Default = Upright.
Default = Upright.
Upright:
Vertical, Top to Bottom:
(Rotate CW 90°)
Upside Down:
Vertical, Bottom to Top:
(Rotate CCW 90°)
* Upright
Upside Down
Vertical, Top to Bottom
Vertical, Bottom to Top

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xenon 1900 and is the answer not in the manual?

Xenon 1900 Specifications

General IconGeneral
Operating Temperature0°C to 50°C (32°F to 122°F)
Storage Temperature-40°C to 70°C (-40°F to 158°F)
ConnectivityUSB, RS-232, Keyboard Wedge
Humidity5% to 95% (non-condensing)
Connectivity TechnologyCorded
Decode Capability1D and 2D barcodes
Light Levels0 to 100, 000 lux
Scanning TechnologyArea Imager
InterfaceUSB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Light SourceLED
