Xenon 1900 User Manual

A - 1
A
Reference Charts
Symbology Charts
Note: “m” represents the AIM modifier character. Refer to International
Technical Specification, Symbology Identifiers, for AIM modifier character
details.
Prefix / Suffix entries for specific symbologies override the universal (All
Symbologies, 99) entry.
Refer to Data Editing beginning on page 5-1 and Data Formatting beginning on
page 6-1 for information about using Code ID and AIM ID.
Linear Symbologies
AIM Honeywell
Symbology ID
Possible
modifiers
(
m )
ID Hex
All Symbologies 99
Codabar ]F m 0-1 a 61
Code 11 ]H3 h 68
Code 128 ]C m 0, 1, 2, 4 j 6A
Code 32 Pharmaceutical
(PARAF)
]X0 < 3C
Code 39 (supports Full ASCII
mode)
]A m 0, 1, 3, 4, 5, 7 b 62
TCIF Linked Code 39
(TLC39)
]L2 T 54
Code 93 and 93i ]G m 0-9, A-Z,
a-m
i 69
EAN ]E m 0, 1, 3, 4 d 64
EAN-13 (including Bookland
EAN)
]E0 d 64
EAN-13 with Add-On ]E3 d 64
EAN-13 with Extended
Coupon Code
]E3 d 64
EAN-8 ]E4 D 44
EAN-8 with Add-On ]E3 D 44

Xenon 1900 Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Connectivity	USB, RS-232, Keyboard Wedge
Humidity	5% to 95% (non-condensing)
Connectivity Technology	Corded
Decode Capability	1D and 2D barcodes
Light Levels	0 to 100, 000 lux
Scanning Technology	Area Imager
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Light Source	LED
