Xenon 1900 User Manual

12 - 6
CCB01-010BT Charge Base Product
Specifications
Parameter Specification
Dimensions (Typical):
Height
3.2 inches (8.13cm)
Length
5.19 inches (13.18cm)
Width
3.98 inches (10.11cm)
Weight
6.3 oz (179g)
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port
500mA
Aux Power Port
1A
Charge Time 5 hours
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
33 ft. (10 m) typical
Data Rate
Up to 1 MBps
Temperature Ranges:
Operating
32° F to +122° F (0° C to +50° C)
Battery Charge
41° F to +104° F (5° C to +40° C)
Storage
-40° F to +158° F (-40° C to +70° C)
Humidity Up to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 3.28 feet
(1 m) to concrete
Vibration 5G Peak from 22Hz to 300Hz
ESD Sensitivity
Up to 15kV direct air
Up to 8 kV indirect coupling plane

Xenon 1900 Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Connectivity	USB, RS-232, Keyboard Wedge
Humidity	5% to 95% (non-condensing)
Connectivity Technology	Corded
Decode Capability	1D and 2D barcodes
Light Levels	0 to 100, 000 lux
Scanning Technology	Area Imager
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Light Source	LED
