Xenon 1900 User Manual

13 - 4
Replacing Cables and Batteries
in Cordless Systems
Replacing an Interface Cable in a Base
1. Turn the power to the host system OFF.
2. Disconnect the base’s cable from the terminal or computer.
3. Turn the base upside down.
4. Pull the connector out while maintaining pressure on the connector
release clip.
5. Replace with the new cable.
Insert the connector into the opening and press firmly. The connector
is keyed to go in only one way, and will click into place.
CCB01-010BT Base :
CCB02-100BT Base :

Xenon 1900 Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Connectivity	USB, RS-232, Keyboard Wedge
Humidity	5% to 95% (non-condensing)
Connectivity Technology	Corded
Decode Capability	1D and 2D barcodes
Light Levels	0 to 100, 000 lux
Scanning Technology	Area Imager
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Light Source	LED
