Xenon 1900 User Manual

8 - 9
IF- Noise Reduction
Used to reduce the salt and pepper noise in an image.
0if No salt and pepper noise reduction (default)
1if Salt and pepper noise reduction
IR - Image Rotate
0ir Image as snapped (rightside up) (default)
1ir Rotate image 90 degrees to the right
2ir Rotate image 180 degrees (upside down)
3ir Rotate image 90 degrees to the left
Example of Noise Reduction On (1if):Example of Noise Reduction Off (0if):
Example of Image Rotate set to 0ir:
Example of Image Rotate set to 2ir:
Example of Image Rotate set to 1ir: Example of Image Rotate set to 3ir:

Xenon 1900 Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Connectivity	USB, RS-232, Keyboard Wedge
Humidity	5% to 95% (non-condensing)
Connectivity Technology	Corded
Decode Capability	1D and 2D barcodes
Light Levels	0 to 100, 000 lux
Scanning Technology	Area Imager
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Light Source	LED
