Xenon 1900 User Manual

1 - 9
Note: The power supply must be ordered separately, if needed.
4. If you are connecting a CCB01-010BT Base, make sure the cables are
secured in the wireways in the bottom of the cordless base and the
base sits flat on a horizontal surface. If you are connecting a CCB02-
100BT Base, see Mounting a CCB02-100BT Base on page 1-11.
5. Plug the serial connector into the serial port on your computer.
Tighten the two screws to secure the connector to the port.
6. Once the scanner or cordless base has been fully connected, power
up the computer.
This interface programs 115,200 baud, 8 data bits, no parity, and 1 stop bit.
CCB02-100BT Base
RS232 Serial Port Connection:

Xenon 1900 Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Connectivity	USB, RS-232, Keyboard Wedge
Humidity	5% to 95% (non-condensing)
Connectivity Technology	Corded
Decode Capability	1D and 2D barcodes
Light Levels	0 to 100, 000 lux
Scanning Technology	Area Imager
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Light Source	LED
